1. Long-Life & Safe LFP Battery
76.8 kWh LFP system with 4,000+ cycles delivers safe, stable, and long-lasting energy storage.
2. Reliable Power When It Matters
65 kW output with overload capability ensures dependable power for critical commercial and jobsite loads.
3. Flexible Hybrid Energy Solution
Seamlessly integrates with the grid, diesel generators, and PV systems for backup or hybrid applications.
4. Easy to Deploy & Expand
Plug-and-play power connections and parallel support simplify installation and future capacity expansion.
| Battery system | Rated capacity(kWh) | 76.8 |
| Battery chemistry | LFP(Lithium Iron Phosphate) | |
| Max. system efficiency(%) | 90 | |
| Expected cycle life(up to 80% of original capacity | >4000 times | |
| Isolation menthod | Power frequency isolation | |
| Output power | kW/kVA overload(<3min) | 100/100 |
| kW/kVA nominal | 65/65 | |
| System output power | Overload (<3min) current(A) | 145 |
| Rated current(A) | 93.8 | |
| Voltage(VAC) | 400±10%(adjustable) | |
| Max.bypass power(A) | 63 | |
| Frequency(Hz) | 50±3 | |
| Connection method | 3P4L | |
| Output connector | 125A aviation power plug | |
| Independent charging interface | Voltage(VAC) | 400±20% |
| Max.charging rate(kW) | 20 | |
| Input connector | 63A aviation power plug | |
| Support type | Power Grid/Diesel Generator(≤100kVA) | |
| Generator interface | Power interface | 100~500kVA |
| Control interface | Dry contact relay,Ethernet,RS485 | |
| PV interface | PV DC coupling(kW) | 30 |
| PV AC coupling(kW) | 10~30 | |
| System architecture | In parallel | Support |
| Communication interface | Ethernet,RS485,4G router | |
| Protection rating | IP55 | |
| Dimension(L*W*H)mm | 1070*1250*2000 | |
| Weight(tons) | 2 | |
| Cooling tyoe | Air cooling | |
| Refrigerating fluid | R134a | |
| Noise emission(dB) | <65 | |
| Temperature range(℃) | -20~50 | |
| Humidity range(%) | 5~95 | |
| Standard | GB/T36276 , GB/T34131 , UL1973 , UL9540A , IEC62619 , UN38.3 , UN3480 | |
