1. Long-Life & Safe LFP Battery
1044.9 kWh LFP system with 6,000+ cycles ensures safe, thermally stable, and long-life energy storage for commercial and industrial use.
2. Higher Apparent Power for Demanding Loads
500 kW / 500 kVA nominal output with up to 550 kVA surge capability, delivering strong support for equipment startup and high-impact loads.
3. Flexible Hybrid Energy Solution
Compatible with the grid, diesel generators, and PV systems, making it ideal for backup power and hybrid energy deployment.
4. Easy to Deploy & Expand
Designed for copper bar connections and parallel operation, allowing fast installation and scalable system expansion.
| Battery system | Rated capacity(kWh) | 1044.9 |
|---|---|---|
| Battery chemistry | LFP(Lithium Iron Phosphate) | |
| Max. system efficiency(%) | 90 | |
| Expected cycle life(up to 80% of original capacity | >6000 times | |
| Isolation method | Power frequency isolation | |
| Output power | kW/kVA overload(<3min) | 500/550 |
| kW/kVA nominal | 500/500 | |
| System output power | Overload (<3min) current(A) | 1000 |
| Rated current(A) | 760 | |
| Voltage(VAC) | 400±10%(adjustable) | |
| Max.bypass power(A) | / | |
| Frequency(Hz) | 50±3 | |
| Connection method | 3P4L | |
| Output connector | Connect to copper bar 1200A | |
| Independent charging interface | Voltage(VAC) | 400±20% |
| Max.charging rate(kW) | 160 | |
| Input connector | 160A terminal 2 branch inputs | |
| Support type | Power Grid/Diesel Generator(≤100kVA) | |
| Generator interface | Power interface | 200~600kVA |
| Control interface | Dry contact relay,Ethernet,RS485 | |
| PV interface | PV DC coupling(kW) | Customized |
| PV AC coupling(kW) | 20~100 | |
| System architecture | In parallel | Support |
| Communication interface | Ethernet,RS485,4G router | |
| Protection rating | IP55 | |
| Dimension(L*W*H)mm | 5800*2000*2400 | |
| Weight(tons) | ≈10 | |
| Cooling type | Liquid cooling | |
| Refrigerating fluid | 50%water+50%Ethylene Glycol(EG) | |
| Noise emission(dB) | <65 | |
| Temperature range(℃) | -20~50 | |
| Humidity range(%) | 5~95 | |
| Standard | GB/T36276 , GB/T34131 , UL1973 , UL9540A , IEC62619 , UN38.3 , UN3480 | |
