1. Long-Life & Safe LFP Battery
2276 kWh LFP system with 6,000+ cycles ensures safe, thermally stable, and long-life energy storage for commercial and industrial use.
2. Higher Apparent Power for Demanding Loads
2500 kW nominal output with up to 2750 kW overload for 3 minutes, delivering exceptional surge resistance for large industrial equipment and critical infrastructure.
3. Flexible Hybrid Energy Solution
Compatible with the grid, diesel generators, and PV systems, making it ideal for backup power and hybrid energy deployment.
4. Easy to Deploy & Expand
Designed for copper bar connections and parallel operation, allowing fast installation and scalable system expansion.
| Battery system | Rated capacity(kWh) | 2276 |
|---|---|---|
| Battery chemistry | LFP(Lithium Iron Phosphate) | |
| Max. system efficiency(%) | 90 | |
| Expected cycle life(up to 80% of original capacity | >6000 times | |
| Isolation method | Power frequency isolation | |
| Output power | kW/kVA overload(<3min) | 2750/2750 |
| kW/kVA nominal | 2500/2500 | |
| System output power | Overload (<3min) current(A) | 160 |
| Rated current(A) | 145 | |
| Voltage(VAC) | 12±2%(adjustable) | |
| Max.bypass power(A) | / | |
| Frequency(Hz) | 50±3 | |
| Connection method | 3P3L | |
| Generator interface | Power interface | ≤2MVA |
| Control interface | Dry contact relay,Ethernet,RS485 | |
| PV interface | PV AC coupling(kW) | 500 |
| System architecture | Communication interface | Ethernet,RS485,4G router |
| Protection rating | IP55(transformer)、IP66(PCS) | |
| Dimension(L*W*H)mm | 6058*2438*2896(without battery compartment) | |
| Weight(tons) | ≈11 | |
| Transformer Cooling | Air cooling | |
| Converter Cooling | Liquid cooling | |
| Noise emission(dB) | <80 | |
| Temperature range(℃) | -20~50 | |
| Humidity range(%) | 5~95 | |
| Standard | GB/T36276 , GB/T34131 , UL1973 , UL9540A , IEC62619 , UN38.3 , UN3480 | |
