1. Long-Life & Safe LFP Battery
261 kWh LFP system with 6,000+ cycles delivers safe, stable, and long-lasting energy storage.
2. Reliable Power When It Matters
130 kW nominal output with up to 195 kW overload for 3 minutes, delivering strong surge resistance for equipment startup and critical load protection.
3. Flexible Hybrid Energy Solution
Seamlessly integrates with the grid, diesel generators, and PV systems for backup or hybrid applications.
4. Easy to Deploy & Expand
Plug-and-play power connections and parallel support simplify installation and future capacity expansion.
| Battery system | Rated capacity(kWh) | 261 |
| Battery chemistry | LFP(Lithium Iron Phosphate) | |
| Max. system efficiency(%) | 90 | |
| Expected cycle life(up to 80% of original capacity | >6000 times | |
| Isolation menthod | Power frequency isolation | |
| Output power | kW/kVA overload(<3min) | 195/195 |
| kW/kVA nominal | 130/130 | |
| System output power | Overload (<3min) current(A) | 282 |
| Rated current(A) | 187.6 | |
| Voltage(VAC) | 400±10%(adjustable) | |
| Max.bypass power(A) | / | |
| Frequency(Hz) | 50±3 | |
| Connection method | 3P4L | |
| Output connector | Connect to copper bar 800A | |
| Independent charging interface | Voltage(VAC) | 400±20% |
| Max.charging rate(kW) | 40/80 | |
| Input connector | 80A terminal | |
| Support type | Power Grid/Diesel Generator(≤100kVA) | |
| Generator interface | Power interface | 100~500kVA |
| Control interface | Dry contact relay,Ethernet,RS485 | |
| PV interface | PV DC coupling(kW) | Customized |
| PV AC coupling(kW) | 20~80 | |
| System architecture | In parallel | Support |
| Communication interface | Ethernet,RS485,4G router | |
| Protection rating | IP55 | |
| Dimension(L*W*H)mm | 2250*1950*2400 | |
| Weight(tons) | ≈5 | |
| Cooling tyoe | Liquid cooling | |
| Refrigerating fluid | 50%water+50%Ethylene Glycol(EG) | |
| Noise emission(dB) | <65 | |
| Temperature range(℃) | -20~50 | |
| Humidity range(%) | 5~95 | |
| Standard | GB/T36276 , GB/T34131 , UL1973 , UL9540A , IEC62619 , UN38.3 , UN3480 | |
