1. Long-Life & Safe LFP Battery
115.2 kWh LFP system with 4,000+ cycles delivers safe, stable, and long-lasting energy storage.
2. Reliable Power When It Matters
100 kW output with overload capability ensures dependable power for critical commercial and jobsite loads.
3. Flexible Hybrid Energy Solution
Seamlessly integrates with the grid, diesel generators, and PV systems for backup or hybrid applications.
4. Easy to Deploy & Expand
Plug-and-play power connections and parallel support simplify installation and future capacity expansion.
| Battery system | Rated capacity(kWh) | 115.2 |
| Battery chemistry | LFP(Lithium Iron Phosphate) | |
| Max. system efficiency(%) | 90 | |
| Expected cycle life(up to 80% of original capacity | >4000 times | |
| Output power | Nominal power kW/kVA | 100/100 |
| Rated current(A) | 150 | |
| Voltage(VAC) | 400±10%(adjustable) | |
| Max.bypass power(A) | 200 | |
| Frequency(Hz) | 50±3 | |
| Connection method | 3P4L | |
| Output connector | connect to copper bar 200A | |
| Grid interface | Voltage(VAC) | 400±10% |
| Input connector | connect to copper bar 200A | |
| Generator interface | Input interface | ≤180kVA |
| Input connector | connect to copper bar 200A | |
| Control interface | Dry contact relay,Ethernet,RS485 | |
| PV interface | PV DC coupling(kW) | 8 sets of PV4.0 standard interfaces,maximum total current 100A |
| PV AC coupling(kW) | Custon-made | |
| System architecture | Communication interface | Ethernet,RS485,4G router |
| Protection rating | IP55 | |
| Dimension(L*W*H)mm | 1300*1140*2200(including air conditioning) | |
| Weight(tons) | 2 | |
| Cooling tyoe | Air cooling | |
| Refrigerating fluid | R134a | |
| Noise emission(dB) | <65 | |
| Temperature range(℃) | -20~50 | |
| Humidity range(%) | 5~95 | |
| Standard | GB/T36276 , GB/T34131 , UL1973 , UL9540A , IEC62619 , UN38.3 , UN3480 | |
